General Features

• Single- or double-sided lamination
• Standard built-in card flattener
• Operates while connected to Primacy2 or in standalone mode

Lamination Performances1

• Single-side: up to 215 cards/hour
• Double-side: up to 110 cards/hour

Card Management and Specifications

• Feeder capacity (from Primacy): 100 cards (0.76 mm – 30 mil)
• Output hopper capacity: 100 cards (0.76 mm – 30 mil)
• Reject tray capacity (from Primacy): 100 cards (0.76 mm – 30 mil)
• Manual card insertion in standalone mode
• Card thickness: 0.76 mm (30 mil)
• Card types: PVC cards, composite PVC cards, PET cards, polycarbonate cards, special varnished cards
• Card format: ISO CR80 – ISO 7810 (53.98 mm x 85.60 mm)

Interfaces

• Infrared (no cable): connection kit with Primacy included
• USB for the CLM in standalone mode (USB cable not provided – reference A5017)

Security

• Support for Kensington® security lock

Display

• LED printer
• Graphical notifications: cleaning alerts, empty/low level ribbon, etc
• LCD screen as an option3

Evolis High Trust® Films
To maximize the quality and durability of printed cards, the lifespan of the print head and lamination module reliability, use Evolis High Trust® films.

• Automatic identification and setting
• Color matching for easy installation
• Available films:

– Clear patch (0.5 ou 1.0 mil): 600 sides / roll

– Holographic Patch (0.6 ou 1.0 mil): 600 sides / roll

– Patch cut out contact chip (0.5 ou 1 mil): 600 sides / roll

– Alternate clear patch 1.0 mil (full / mag cut): 600 sides / roll

– Alternate clear patch 1.0 mil (smart cut / full): 600 sides / roll

– Alternate clear patch 1.0 mil (smart cut / mag out): 600 sides / roll

– Clear varnish: 1200 sides / roll

– Continuous holographic varnish: 1200 sides / roll

– Registered holographic varnish: 1200 sides / roll

– Other films upon request

A list of all of lamination films can be found on www.evolis.com

Option

• Installation of a second Card Lamination Module (CLM) to
• laminate both sides of the card with two different films3

Software
Evolis Premium Suite®

Certifications and Statement of Compliance

• CE, FCC, ICES, VCCI
• RoHS

Size and Weight

• CLM :

– Size (H x W x D): 269 x 205 x 370 mm (10.59’’ x 8.07’’ x 14.56’’)
– Weight: 6 kg (13.22 lbs)

• With Primacy :

– Size (H x W x D): 269 x 205 x 753 mm (10.59’’ x 8.07’’ x 29.64’’)
– Weight: 10 kg (22.04 lbs)
Warranty4

• 3-year warranty
• Warranty extension available as an option
